вступ
Thank you for choosing the Yaheetech Steel Rack. This instruction manual provides detailed information on the assembly, operation, maintenance, and troubleshooting of your new storage unit. Please read this manual carefully before assembly and retain it for future reference to ensure safe and efficient use of the product.
Image: The Yaheetech 4-tier steel rack, featuring a black metal frame and light wood-colored MDF shelves. This image provides a clear view of the product's overall design and structure.
Техніка безпеки
Щоб запобігти травмуванню або пошкодженню виробу, дотримуйтесь наступних правил безпеки:
- Always assemble the rack on a flat, stable surface.
- Wear the provided gloves during assembly to protect your hands from sharp edges.
- Do not overload the shelves. Ensure weight is evenly distributed. Each shelf has a maximum load capacity of 265kg.
- Do not climb on the rack or allow children to play on or around it.
- Secure the rack to a wall if there is any risk of tipping, especially in areas with children or pets.
- Тримайте дрібні деталі подалі від дітей, щоб запобігти небезпеці задухи.
Вміст упаковки
Перед початком складання перевірте наявність та цілісність усіх перелічених нижче компонентів. Якщо якісь деталі відсутні або пошкоджені, зверніться до служби підтримки клієнтів.
- Steel Upright Posts
- Steel Beams (horizontal supports)
- MDF Shelf Boards
- Anti-slip Rubber Feet (8 pieces)
- Assembly Gloves (1 pair)
Image: This image displays the essential accessories included with the Yaheetech steel rack: a pair of blue and white assembly gloves for hand protection and eight black anti-slip rubber feet designed to protect your floor and enhance stability.
Інструкції зі складання
Уважно виконайте ці кроки для правильного складання. Для легшого та безпечнішого складання рекомендується залучати двох людей.
- Підготуйте робоче місце: Clear a spacious, flat area for assembly. Lay out all components and ensure you have the included gloves.
- Assemble the Upright Frames: Connect the shorter upright posts to form the full height of the rack using the provided steel joints. Ensure all connections are secure.
- Прикріпіть горизонтальні балки: Insert the horizontal beams into the slots on the upright posts at your desired shelf heights. The screwless design allows for easy slotting. Ensure each beam is firmly seated in its slot.
- Insert MDF Shelf Boards: Once the frame is complete, carefully place the MDF shelf boards onto the assembled horizontal beams. Ensure they sit flush and are stable.
- Прикріпіть протиковзкі ніжки: Place the rubber anti-slip feet onto the bottom of each upright post. These protect your floor and provide additional stability.
Image: This diagram illustrates the key features and components for assembly, including the adjustable height mechanism, the screwless interlocking design for easy setup, the durable MDF shelf boards, and the protective anti-slip feet.
Зображення: Детальне views highlighting the rubber caps at the base of the rack, which prevent floor scratches and enhance stability, and the innovative screwless design of the metal frame, ensuring quick and easy assembly without the need for tools.
Інструкція з експлуатації
Регулювання висоти полиці
The Yaheetech Steel Rack features adjustable shelf heights, allowing you to customize the storage space according to your needs. To adjust a shelf:
- Спорожніть полицю, яку потрібно налаштувати.
- Carefully lift the MDF board off the beams.
- Disengage the horizontal beams from their current slots on the upright posts.
- Re-insert the beams into the desired slots at the new height. Ensure they are securely locked into place.
- Place the MDF board back onto the beams.
Image: This visual demonstrates the adjustable height capability of the rack. Arrows indicate that the shelves can be moved up or down along the upright posts, allowing for flexible customization of storage space to fit various item sizes.
Customizing Configuration
This versatile rack can be configured in multiple ways to suit different spaces and storage requirements. It can be assembled as a single tall unit or split into two shorter, separate units, or even combined to form a workbench.
Зображення: Діаграмаasing the rack's modular design, allowing it to be assembled as a single tall unit, two smaller independent units, or an L-shaped workbench, providing adaptability for diverse storage needs and spaces.
Технічне обслуговування та догляд
Proper maintenance will ensure the longevity and appearance of your Yaheetech Steel Rack:
- Прибирання: Wipe down the steel frame and MDF boards with a soft, damp cloth. For stubborn dirt, a mild soap solution can be used, followed by a dry cloth.
- Уникайте агресивних хімікатів: Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the coating on the steel and the MDF boards.
- Сухе середовище: While the frame has a rust-resistant coating, it is best to use the rack in a dry environment to prevent moisture buildup on the MDF boards.
- Регулярна перевірка: Періодично перевіряйте всі з’єднання, щоб переконатися, що вони міцні та надійні.
Image: This image highlights the ease of maintenance for the rack, depicting a hand wiping down a shelf, emphasizing that the surfaces are simple to clean and keep tidy.
Усунення несправностей
If you encounter any issues with your Yaheetech Steel Rack, please refer to the following table for common problems and their solutions:
| проблема | Можлива причина | Рішення |
|---|---|---|
| Стійка відчувається нестабільною або хиткою. | Connections not fully secured; uneven floor; overloaded. | Ensure all beams are fully seated in their slots. Check that the rack is on a level surface. Distribute weight evenly and do not exceed load capacity. |
| Difficulty inserting beams into slots. | Beams are not aligned correctly; burrs on slots. | Ensure the beam ends are perfectly aligned with the slots. Apply gentle pressure. If burrs are present, carefully remove them (wear gloves). |
| MDF boards do not sit flat. | Beams are not level or fully engaged. | Check that all four beams supporting the board are at the same height and fully locked into their respective slots. |
Технічні характеристики продукту
Detailed specifications for the Yaheetech Steel Rack (Model 611273):
| Особливість | Специфікація |
|---|---|
| Бренд | Yaheetech |
| Номер моделі | 611273 |
| Розміри продукту (Д x Ш x В) | 150 x 45 x 180 см (59.1 x 17.7 x 70.9 дюйма) |
| Вага товару | 27.6 кг (60.8 фунта) |
| Колір | чорний |
| матеріал | 0.85mm Steel Plate, 6mm MDF Board |
| Вантажопідйомність полиці | 265kg (584 lbs) per shelf (evenly distributed) |
| Загальна вантажопідйомність | 1060 кг (2337 фунти) |
| особливості | Adjustable height, Anti-slip feet, Screwless assembly |
| Тип кімнати | Basement, Storage Room, Workshop, Warehouse, Shop, Home, Bedroom, Living Room |
| Тип полиці | 4-tier rack |
| Кількість полиць | 4 |
| Форма | Прямокутний |
| Стиль | Сучасний |
| Цільова аудиторія | Дорослий |
Image: A visual representation of the product's specifications, detailing its material composition (stainless steel, MDF board), overall dimensions, weight, maximum load capacity per shelf, and color.
Гарантія та підтримка
Компанія Yaheetech прагне надавати високоякісну продукцію та задовольнити потреби клієнтів. Хоча конкретні деталі гарантії не наведені в цьому посібнику, будь ласка, збережіть підтвердження покупки для будь-яких гарантійних претензій.
For product support, troubleshooting assistance, or to inquire about warranty information, please contact Yaheetech customer service through the retailer where you purchased the product or visit the official Yaheetech brand store:
