ULTRALOQ U-Bolt Pro Smart Lock with Door Sensor Instruction Manual

1. Вступ

The ULTRALOQ U-Bolt Pro Smart Lock with Door Sensor provides advanced security and convenient access to your home. This manual guides you through the installation, setup, operation, and maintenance of your smart lock, ensuring optimal performance and peace of mind.

2. Продукт закінчивсяview

The ULTRALOQ U-Bolt Pro Smart Lock offers multiple ways to access your property, combining traditional and modern security features. It is designed for easy DIY installation and integrates seamlessly with various smart home ecosystems.

• 6-в-1 безключовий доступ: Access via 360° Fingerprint ID, Anti-peep Keypad, Smartphone App, Auto Unlock, Auto Lock, and Mechanical Key.
• Вбудований WiFi: Remote control and monitoring from anywhere without an additional hub.
• Датчик дверей: Enables smart auto-lock and provides real-time door status.
• Високий рівень безпеки: ANSI Commercial Grade 1 certified, offering superior strength and durability.
• Стійкий до погодних умов: IP65 rated external lock, built to withstand various weather conditions.
• Сумісність із Smart Home: Works with Amazon Alexa, Google Assistant, SmartThings, and IFTTT.

3. Що входить до комплекту

Перед початком встановлення перевірте наявність усіх компонентів:

• ULTRALOQ U-Bolt Pro WiFi Smart Lock (Exterior Assembly with Keypad and Fingerprint Scanner)
• Interior Assembly (with thumb-turn and battery compartment)
• Монтажна пластина
• Засувний засув
• Запірна пластина та запірна коробка
• Датчик дверей
• Резервні ключі (2)
• Лужні батарейки типу АА (4)
• Кріпильні елементи (гвинти, болти)
• Посібник із встановлення та користувача

Image: All components of the ULTRALOQ U-Bolt Pro Smart Lock, including the exterior keypad, interior assembly, deadbolt, mounting hardware, and keys.

4. Монтаж

The ULTRALOQ U-Bolt Pro Smart Lock is designed for simple DIY installation, typically taking minutes with just a screwdriver. Ensure your door has a separate deadbolt from the main handle for proper fitment.

1. Видалити існуючий ригель: Unscrew and remove your current deadbolt assembly from the door.
2. Install New Deadbolt Latch: Insert the new deadbolt latch into the door edge and secure it with the provided screws.
3. Встановити зовнішню збірку: Carefully align the exterior keypad assembly with the deadbolt latch, ensuring the spindle passes through the latch mechanism. Feed the connecting cable through the door.
4. Встановити монтажну пластину: On the interior side of the door, attach the mounting plate, feeding the cable through the plate's opening. Secure it with the long screws provided, ensuring a snug fit.
5. З’єднання внутрішнього блоку: Connect the cable from the exterior assembly to the interior assembly. Mount the interior assembly onto the mounting plate, ensuring the spindle engages correctly. Secure with screws.
6. Вставте батареї: Відкрийте кришку батарейного відсіку на внутрішньому блоці та вставте чотири лужні батарейки типу АА.
7. Install Door Sensor: Attach the door sensor to the door frame, aligning it with the interior assembly for accurate door status detection.

Image: Step-by-step diagram illustrating the installation process of the smart lock.

5. Налаштування

5.1. Налаштування програми

Download the U-tec App from your smartphone's app store. Create an account and follow the on-screen instructions to add your U-Bolt Pro Smart Lock. You will be prompted to create an Admin PIN during this process.

Image: The U-tec app displaying lock status, user management, and log records.

5.2. Google Assistant Setup

To connect your ULTRALOQ U-Bolt Pro with Google Assistant, ensure your lock is paired with the U-tec App, your Google Assistant device is on and connected to WiFi, and your smartphone is connected to WiFi.

1. Open the U-tec App and ensure your lock is listed and named (e.g., "Front Door").
2. Відкрийте програму Google Home.
3. Tap the User Logo (bottom right).
4. Торкніться «Додаткові налаштування».
5. Tap "Assistant" then "Home Control".
6. Tap the "+" button (bottom right) to add a device.
7. Tap the Search button (top right) and search for "U-tec". Select "U-tec Smart Home".
8. Log in to your U-tec account and tap "Authorize".
9. Set a security code. Google Assistant will ask for this when unlocking your Ultraloq.
10. Choose your device location and select your lock.

5.3. SmartThings Setup

To connect your ULTRALOQ U-Bolt Pro with SmartThings, ensure your lock is connected to your home WiFi and you have registered in the SmartThings App.

1. Open your SmartThings App and select the "Devices" tab page.
2. Tap the "+" button on the top-right corner.
3. Find "U-tec" in the list of brands.
4. Tap "Door Locks", then "Ultraloq Smart Lock with WiFi Access".
5. Log in to your U-tec account in SmartThings and tap "Authorize".
6. Tap "Done" to quit the site.

6. Режими роботи

6.1. Fingerprint ID

The 360° Live Fingerprint Identification allows for fast and accurate biometric detection from any angle. Simply place your registered finger on the sensor to unlock.

Image: A hand using the fingerprint sensor on the smart lock for access.

6.2. Клавіатура з антипіп

Enter your 4-8 digit entry code on the backlit numeric keypad. The anti-peep feature allows you to input random digits before or after your actual code to prevent others from guessing your password.

6.3. Smartphone Control

Use the U-tec App to lock, unlock, share access (eKeys or codes), and view a log of who entered and when, all remotely via the built-in WiFi.

6.4. Smart Auto Lock and Auto Unlock

The smart lock automatically locks if your door closes (with the door sensor installed). The auto-unlock feature allows the door to unlock when you arrive with your smartphone in your pocket (requires setting up a geofence in the app).

Image: The smart lock and door sensor indicating the door is closed and locked via the app.

6.5. Механічний ключ

A hidden keyhole provides traditional backup access in case of battery failure or other electronic issues. Simply slide up the bottom cover of the exterior assembly to reveal the keyhole.

7. Інтеграція «Розумний дім».

The ULTRALOQ U-Bolt Pro Smart Lock integrates with popular smart home platforms:

• Amazon Alexa: Control your lock with voice commands.
• Google Assistant: Control your lock with voice commands.
• SmartThings: Integrate into your broader smart home ecosystem.
• IFTTT: Create custom automations and triggers.

Image: Voice control of the smart lock using Amazon Alexa.

8. Технічне обслуговування

8.1. Термін служби батареї

The U-Bolt Pro WiFi is powered by 4 AA alkaline batteries. It can provide up to 6,000 accesses. On average, with 20 uses per day, the battery life can last up to 1 year. The U-tec App will provide low battery alerts, giving you ampчас замінити батарейки.

8.2. Backup Power

In case of complete battery depletion, you can use a 9V battery as an emergency power source by touching it to the terminals on the bottom of the exterior assembly, or use the mechanical backup key.

Image: Using a 9V battery to temporarily power the lock for emergency access.

9. Вирішення проблем

9.1. Auto-Lock Engaged Unexpectedly

The auto-lock feature is turned on by default. If the door closes, the lock will automatically engage. Ensure you have your smartphone or a backup key with you when testing the lock to avoid being locked out. This setting can be adjusted in the U-tec App.

9.2. Проблеми з підключенням

The lock connects via 2.4GHz WiFi only (802.11 b/g/n). Ensure your router is configured to support 2.4GHz and that your smartphone is connected to the same network during setup. Some advanced router features like BSS Transition (801.11r) can cause issues with IoT devices; disabling these may improve connectivity.

9.3. Fingerprint Reader Not Recognizing

Ensure your finger is clean and dry. Re-register your fingerprint if issues persist. For children, ensure their fingerprints are fully developed for reliable recognition.

10. Технічні характеристики

11. Гарантія та підтримка

ULTRALOQ provides a lifetime mechanical warranty and an 18-month electronic warranty for the U-Bolt Pro Smart Lock. For support, please visit the ULTRALOQ official webсайту або зв’яжіться зі службою підтримки клієнтів.
