Electactic HZB-15YLR Water Dispenser with Ice Maker Function User Manual

вступ

This manual provides essential instructions for the safe and efficient operation, installation, and maintenance of your Electactic HZB-15YLR Water Dispenser with Ice Maker Function. Please read this manual thoroughly before using the appliance and retain it for future reference.

Важлива інформація з безпеки

• Завжди переконайтеся, що прилад встановлено на стійкій, рівній поверхні.
• Не використовуйте прилад із пошкодженим шнуром живлення або вилкою.
• Keep children away from the hot water dispenser. The unit is equipped with a child safety lock for hot water.
• Не занурюйте прилад, шнур або вилку у воду чи інші рідини.
• Від’єднайте прилад від мережі перед чищенням або будь-яким технічним обслуговуванням.
• Забезпечте належну вентиляцію навколо пристрою.

Продукт закінченийview

The Electactic HZB-15YLR is a versatile top-loading water dispenser that provides instant hot and cold water, along with an integrated ice maker. It is designed for use with 3 or 5-gallon water bottles.

Зображення: спереду view of the Electactic HZB-15YLR Water Dispenser, showing the top-loading bottle, water dispenser area, and ice maker compartment.

Ключові характеристики:

• Top-loading design for 3 or 5-gallon water bottles.
• Instant hot water (up to 194°F) and cold water (down to 59°F).
• Integrated ice maker producing 9 bullet-shaped ice cubes in approximately 6-8 minutes, with a daily capacity of up to 26 lbs.
• Child safety lock for hot water dispenser.
• LED touchscreen control panel with indicators for heating, cooling, ice-making, power, and "Add Water" reminder.
• Знімний піддон для крапель для легкого очищення.

Інструкції з налаштування

1. Розпакування: Carefully remove the water dispenser from its packaging. Inspect for any damage. Keep the unit in an upright position. If the unit has been tipped during transit, allow it to stand upright for at least 2 hours before plugging it in, similar to a refrigerator, to allow refrigerants to settle.
2. Розміщення: Place the dispenser on a firm, level surface in a cool, dry place away from direct sunlight and heat sources. Ensure there is adequate ventilation around the unit.
3. Встановити пляшку з водою: Remove the cap from a 3 or 5-gallon water bottle and place it securely onto the top-loading receptacle of the dispenser. Ensure the bottle is seated correctly to prevent leaks.
4. Підключення живлення: Plug the power cord into a grounded electrical outlet. The "Power" indicator light on the control panel should illuminate.
5. Початкова експлуатація: Allow the unit to sit for approximately 15-30 minutes after plugging it in before dispensing water or activating the ice maker. This allows the internal tanks to fill and the cooling/heating elements to reach optimal temperatures.

Image: A person placing a 5-gallon water bottle onto the top-loading water dispenser, illustrating the initial setup of the water bottle.

Інструкція з експлуатації

Панель управління завершенаview:

Image: Close-up of the control panel showing buttons for Cold Water Dispense, Child Lock, Hot Water Dispense, Power, Add Water, Heating, Cooling, and Ice-Making indicators.

• Cold Water Dispense: Place your cup under the cold water spout and press the "Cold Water Dispense" button. The cooling indicator light will be on when the water is being cooled.
• Hot Water Dispense (with Child Lock): To dispense hot water, first press and hold the "Child Lock" button for 3 seconds until it unlocks. Then, press the "Hot Water Dispense" button. The heating indicator light will be on when the water is being heated. This safety feature prevents accidental hot water dispensing.
• Ice Maker Function: Ensure the "Ice-Making" indicator light is on. The ice maker will automatically produce bullet-shaped ice cubes and drop them into the lower compartment. Open the ice maker door to access the ice. A scoop is provided for convenience.
• Додати індикатор води: A red "Add Water" light will illuminate when the water bottle is empty and needs to be replaced.

Технічне обслуговування

• Очищення піддону для крапель: The drip tray is removable for easy cleaning. Regularly empty and wash the drip tray with mild soap and water to prevent spills and maintain hygiene.
• Зовнішнє очищення: Протріть зовнішню частину дозатора м’якою тканиноюamp тканина. Не використовуйте абразивні засоби чи розчинники.
• Внутрішнє очищення: For thorough internal cleaning, refer to the detailed instructions in the full product manual. This typically involves draining the tanks and flushing with a cleaning solution.

Image: A hand removing the drip tray from the water dispenser, demonstrating its easy-to-clean design.

Усунення несправностей

Технічні характеристики

Гарантія та підтримка

For warranty information, technical support, or service inquiries, please refer to the official documentation included with your product or contact Electactic customer service directly. Keep your purchase receipt for warranty claims.
