Dabbsson DBS2100B 2150Wh Expansion Battery User Manual

1. Вступ

The Dabbsson DBS2100B is a 2150Wh expansion battery designed to significantly extend the capacity of your Dabbsson Pro Series Portable Power Station (DBS1000Pro, DBS1400Pro, DBS2100Pro). This unit provides additional power for various applications, including outdoor activities and home power backup. It features multiple USB ports for charging devices and supports standalone solar recharging.

Figure 1: Dabbsson DBS2100B Expansion Battery. This image shows the main unit of the Dabbsson DBS2100B expansion battery, highlighting its compact design and robust casing.

2. Інформація про безпеку

Please read all safety instructions carefully before using the Dabbsson DBS2100B expansion battery. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• Не розбирайте, не ремонтуйте та не модифікуйте пристрій.
• Тримайте пристрій подалі від вогню, води та екстремальних температур.
• Забезпечте належну вентиляцію під час використання та заряджання.
• This product is built with safety in mind, featuring FCC/CE EMC Class B certification for home use and UL94 V0 Rating for protection against flame and fall.
• Використовуйте лише схвалені аксесуари та кабелі.

Figure 2: Safety Features of DBS2100B. This image illustrates the robust construction of the Dabbsson DBS2100B, emphasizing its FCC/CE EMC Class B certification and UL94 V0 rating for enhanced safety and durability.

3. Вміст упаковки

Після розпакування, будь ласка, перевірте наявність усіх наступних предметів:

• Додатковий акумулятор DBS2100B
• Посібник користувача (цей документ)
• Картка попередження
• Додатковий кабель акумулятора
• Сонячний зарядний кабель

4. Налаштування

4.1 Connecting to a Pro Series Power Station

The DBS2100B expansion battery is designed to connect with Dabbsson DBS1000Pro, DBS1400Pro, or DBS2100Pro power stations to increase their total energy capacity.

1. Ensure both the DBS2100B and your Pro Series power station are powered off before connecting.
2. Locate the expansion battery port on both the DBS2100B and your Dabbsson Pro Series power station.
3. Use the provided Extra Battery Cable to securely connect the two units.
4. Once connected, power on your Pro Series power station. The DBS2100B will be recognized, and the combined capacity will be displayed.

Примітка: A maximum of two DBS2100B units can be connected to one DBS1000Pro, DBS1400Pro, or DBS2100Pro power station, providing a significant increase in total capacity.

Figure 3: Expanding Power Station Capacity. This image demonstrates how the DBS2100B expands the capacity of a Dabbsson Pro Series power station, showing configurations for increased power output and duration for various appliances.

4.2 Boosting AC Recharge

When the DBS2100B battery is connected to a DBS1000Pro, DBS1400Pro, or DBS2100Pro, the maximum AC input for charging can be boosted up to 1800W. This allows for faster recharging of the combined battery capacity.

• Connect the AC charging cable to your Pro Series power station.
• Plug the AC charging cable into a wall outlet.
• The system will automatically detect the connected DBS2100B and adjust the charging input to the boosted rate.

5. Інструкція з експлуатації

5.1 Standalone USB Charging

The DBS2100B can function as a standalone power supply for smaller devices. It is equipped with:

• Two (2) 100W USB-C ports
• Two (2) 18W USB-A ports

To use these ports:

1. Ensure the DBS2100B is powered on.
2. Connect your device (e.g., phone, laptop, camera) to the appropriate USB-C or USB-A port using a compatible cable.
3. Пристрій почне заряджатися автоматично.

5.2 Standalone Solar Recharging

The DBS2100B features an integrated MPPT (Maximum Power Point Tracking) and solar charging controller, allowing it to be recharged directly by solar panels without needing to be connected to a main power station. It supports up to 1200W of solar input.

1. Position your solar panels in direct sunlight.
2. Connect the solar panels to the DBS2100B using the provided Solar Charging Cable.
3. The unit's display will indicate the charging status and input power.

Figure 4: Standalone Solar Charging. This image shows the Dabbsson DBS2100B connected to solar panels, demonstrating its capability for independent solar recharging with up to 1200W input.

5.3 Smart App Control

Monitor and control your DBS2100B expansion battery using the Dabbsson Smart App. The app allows you to view battery status, input/output power, and manage settings remotely.

1. Download the "Dabbsson" app from the Apple App Store or Google Play Store.
2. Follow the in-app instructions to pair your DBS2100B with your mobile device.
3. Once connected, you can monitor and control the battery's functions from your smartphone.

Figure 5: Dabbsson Smart App Control. This image displays a smartphone screen showing the Dabbsson app interface, which allows users to monitor and control the expansion battery's status and settings.

6. Технічне обслуговування

Proper maintenance ensures the longevity and optimal performance of your DBS2100B expansion battery.

• Зберігання: If storing for extended periods, charge the battery to approximately 50-80% every 3-6 months to prevent deep discharge. Store in a cool, dry place away from direct sunlight.
• Прибирання: Використовуйте суху м’яку тканину для очищення зовнішньої частини пристрою. Не використовуйте агресивні хімікати або абразивні матеріали.
• температура: Avoid operating or storing the unit in extreme temperatures (below 0°C or above 40°C).
• Вентиляція: Ensure ventilation openings are not blocked during operation to prevent overheating.

7. Вирішення проблем

If you encounter issues with your DBS2100B, refer to the following common troubleshooting steps:

• Пристрій не вмикається:
  • Переконайтеся, що кнопку живлення натиснуто міцно.
  • Перевірте, чи акумулятор має достатній заряд.
• Не заряджається:
  • Verify all charging cables are securely connected.
  • If using solar, ensure panels are in direct sunlight and clean.
  • Check the power source (wall outlet or solar panel) is functional.
• Порти USB не працюють:
  • Ensure the DBS2100B is powered on.
  • Try a different USB cable or device to rule out device/cable issues.
• Повідомлення про помилку на дисплеї:
  • Refer to the Dabbsson Smart App or the main power station's manual for specific error code interpretations.
  • Спробуйте перезавантажити пристрій.

Якщо проблема не зникає, зверніться до служби підтримки клієнтів Dabbsson.

8. Технічні характеристики

9. Гарантія та підтримка

9.1 Інформація про гарантію

The Dabbsson DBS2100B comes with a comprehensive warranty. The product includes a 3-Year Warranty with an additional 2-Year Extended Warranty, totaling 5 years of coverage. Please retain your proof of purchase for warranty claims.

9.2 Підтримка клієнтів

For technical assistance, warranty claims, or any other inquiries, please contact Dabbsson customer support. You can find contact details on the official Dabbsson website or through the contact information provided on your warning card.

Інтернет-підтримка: Відвідайте Магазин Dabbsson на Amazon для отримання додаткової інформації та ресурсів підтримки.
