onlyfly Smart WiFi Weather Station User Manual

1. Вступ

This manual provides instructions for the setup, operation, and maintenance of your onlyfly Smart WiFi Weather Station. This device offers accurate indoor and outdoor temperature and humidity monitoring, along with a 5-day weather forecast, a large color display, and smart app connectivity.

Image: The onlyfly Smart WiFi Weather Station main unit and its wireless outdoor sensor.

2. Вміст упаковки

Будь ласка, перевірте наявність усіх предметів у вашій упаковці:

• 1x onlyfly Smart WiFi Weather Station (Main Unit)
• 1x Бездротовий зовнішній датчик
• 1x адаптер змінного струму
• 1x Посібник користувача

3. Особливості продукту

• Integrated WiFi and Tuya Smart App control for automatic time, date, and weather data synchronization.
• Monitors indoor/outdoor temperature and humidity.
• Provides current day and next 4-day weather forecasts, including min/max temperature and UV index.
• 7.5-inch large color display with clear interface.
• Four adjustable backlight levels (High, Medium, Low, Off).
• Three daily alarms with snooze function.
• Supports connection with up to 3 outdoor sensors (one sensor included).
• Temperature unit selection (Celsius/Fahrenheit).
• Perpetual calendar up to 2099 and 12/24 hour time format.
• Temperature alert function.
• Indoor comfort level display.
• USB port for charging electronic devices.
• Dual power modes: AC adapter or 2 AA batteries (main unit); 2 AAA batteries (wireless sensor).

4. Налаштування

4.1 Powering the Weather Station

The main weather station unit can be powered by the included AC adapter or by 2 AA batteries (not included).

1. For continuous power, connect the provided AC adapter to the DC-IN port on the back of the weather station and plug it into a power outlet.
2. For battery backup or portable use, open the battery compartment on the back and insert 2 AA batteries, observing polarity.

Image: The weather station can be powered by 2 AA batteries or the DC power adapter. It also features a USB charging socket.

4.2 Installing Wireless Sensor Batteries

Бездротовий зовнішній датчик працює від 2 батарейок типу ААА (не входять до комплекту).

1. Open the battery compartment on the wireless sensor.
2. Вставте 2 батарейки типу ААА, дотримуючись правильної полярності.
3. Надійно закрийте батарейний відсік.
4. Place the sensor in a suitable outdoor location, protected from direct sunlight and rain, within 60 meters of the main unit.

4.3 Connecting to Wi-Fi (Tuya Smart App)

The weather station uses the Tuya Smart app for advanced features and automatic time synchronization.

Image: The weather station connects to the Tuya Smart app via WiFi for smart system features.

1. Завантажте додаток: шукати "Tuya Smart" in your mobile device's app store (iOS or Android) and install it.
2. Увімкнення: Ensure your weather station is powered on.
3. Увійдіть у режим сполучення: On the weather station, press and hold the "▼/" button for more than 3 seconds until the Wi-Fi icon on the display starts flashing, indicating pairing mode.
4. Відкрити додаток: Launch the Tuya Smart app on your phone.
5. Додати пристрій: In the app, tap the "+" icon to add a new device. Select "Weather 3" or search for "Weather Station".
6. Інформація про Wi-Fi: Follow the on-screen instructions in the app to enter your 2.4 GHz Wi-Fi network name and password. Note: The device only supports 2.4 GHz Wi-Fi networks. If you have a dual-band router, ensure your phone is connected to the 2.4 GHz band during setup.
7. Повне сполучення: Wait for the app to complete the pairing process. Once successful, the Wi-Fi icon on the weather station display will become solid.

5. Інструкція з експлуатації

5.1 Розуміння дисплея

Зображення: Детальне view of the weather station display with labels for each information area.

The 7.5-inch color display provides comprehensive weather and time information:

• A1: Час
• A2: Температура в приміщенні
• A3: Week for Today
• A4: Вологість у приміщенні
• A5: Remote Wireless Channel (for outdoor sensor data)
• A6: Температура на вулиці
• A7: Календар
• A8: Вологість на вулиці
• A9: Predicted Maximum Temperature (today and next 1-4 days)
• A10: Predicted Minimum Temperature (today and next 1-4 days)
• A11: Прогноз погоди (for today and next 1-4 days)
• A12: UV Index

5.2 Регулювання підсвічування

The display backlight has four adjustable levels.

Image: The weather station offers four adjustable backlight levels for various lighting conditions.

Press the dedicated backlight button (often labeled with a sun icon or similar) on the weather station to cycle through High, Medium, Low, and Off brightness settings.

5.3 Налаштування будильників

The weather station supports up to three daily alarms with a snooze function.

Image: The weather station features 3 sets of alarm clocks with a snooze function.

Refer to the specific buttons on your device (usually labeled 'ALARM' or similar) and the detailed instructions in the included printed manual for setting and managing alarms. To activate snooze, touch the top of the weather station when an alarm sounds. The snooze duration is five minutes.

5.4 Вибір одиниці температури

You can switch between Celsius (℃) and Fahrenheit (℉).

Locate the ℃/℉ button on the weather station (often combined with another function button) and press it to toggle between the two temperature units.

5.5 Monitoring Multiple Sensors

The weather station can connect to up to three outdoor sensors.

Image: The weather station supports up to 3 channels, allowing temperature and humidity data from three locations simultaneously.

If you have additional outdoor sensors (purchased separately), ensure they are powered on. The main unit will automatically detect and display data from available sensors. Use the 'CHANNEL' button on the weather station to cycle through the data from different sensors (CH1, CH2, CH3).

6. Технічне обслуговування

• Прибирання: Wipe the weather station and sensor with a soft, dry cloth. Do not use abrasive cleaners or solvents.
• Заміна батареї: Replace batteries in the main unit and wireless sensor when the low battery indicator appears on the display. Ensure correct battery type and polarity.
• Розташування датчика: Periodically check the outdoor sensor's placement to ensure it remains protected from direct weather elements for accurate readings.

7. Вирішення проблем

7.1 No Display / Power Issues

• Ensure the AC adapter is securely plugged into both the weather station and a working power outlet.
• If using batteries, check that they are inserted correctly with the right polarity and are not depleted. Replace if necessary.

7.2 Wi-Fi Connection Failure

• Мережа 2.4 ГГц: Confirm your Wi-Fi network is 2.4 GHz. The weather station does not support 5 GHz networks. If you have a dual-band router, ensure your phone is connected to the 2.4 GHz band during setup.
• Password Accuracy: Double-check that the Wi-Fi password entered in the Tuya Smart app is correct.
• Близькість: Ensure the weather station is close to your Wi-Fi router during the initial setup process.
• Перезавантаження роутера: Спробуйте перезавантажити Wi-Fi роутер.
• Reset Pairing Mode: If the Wi-Fi icon is not flashing, press and hold the "▼/" button for more than 3 seconds to re-enter pairing mode.
• Проблеми з програмою: Ensure your Tuya Smart app is updated to the latest version.

7.3 Outdoor Sensor Not Displaying Data

• Акумулятори: Check and replace the AAA batteries in the wireless sensor.
• діапазон: Ensure the sensor is within the 60-meter transmission range of the main unit and there are no major obstructions (thick walls, metal objects) between them.
• Перешкоди: Move the sensor or main unit away from potential sources of electromagnetic interference (e.g., other wireless devices, large electronics).
• Повторна синхронізація: Power cycle both the main unit and the outdoor sensor. The main unit should automatically search for and connect to the sensor.

7.4 Неточні показники

• Розташування датчика: Ensure the outdoor sensor is not in direct sunlight, near heat sources, or exposed to heavy rain, which can affect accuracy.
• Вентиляція: Ensure both indoor and outdoor sensors have adequate airflow around them.

8. Технічні характеристики

9. Гарантія та підтримка

This product comes with a standard manufacturer's warranty. For detailed warranty information, please refer to the documentation provided with your purchase or contact the retailer. For technical support or further assistance, please reach out to the customer service department of your place of purchase.
